Open frame power supplies
- Product name: Open frame power supplies, power module, 36W/48W, input 100-240V, output 3-24V
- Lead Time :25–30 days
- US$ 3.12 - 3.21 / Piece
- Minimum order quantity: 1000 Pieces
- Model Number:HP48B
产品描述
Key Specifications/Special Features:
Input
Input Range:100-240VAC
Frequency:50-60 Hz
Input Current:≤0.6A
Inrush Current:≤60A
Efficiency:Meet CEC Level VI (DoE), CoC Tier 2
Hold Up Time: ≥8.3mS
Turn On Time:≤3S
Environmental
Operating Temperature:0-40℃
Storage Temperature :-20-85℃
Operating Humidity:10%-90%
Storage Humidity:5%-95%
Safety
UL/cUL, ETL, FCC, PSE, GS, CE, CCC, LVD, SAA,BS,TUV
Electrical Specifications
Max. Output Power (W):36W/48W
Output Voltage (vo):3-24V
Min. Load (io):0.1-2.4A
Ripple & Noise:100mV
Features
DoE Compliance
RoHS Compliance
Over Voltage Protective Installation
Short Voltage Protective Installation
Protection Type: Auto Recovery
MTBF: 100,000 hrs
Main Export Markets
- North America
- Western Europe
